Three pieces electric actuated ball valve is an important actuator in industrial automation control system. The change of the valve seat port is proportional to the stroke of the valve disc. It is mainly used to cut off or connect the medium in the pipeline, and can also be used for the regulation and control of the fluid. It is a pipeline pressure element for industrial automation process control.
• Direct mount ISO5211 Full Port stainless steel ball valve
• 3-piece swing out body designed for easy maintenance
• 1000 PSI working pressure at 100°F (38°C)
• Visual valve position indicator
• Heavy duty motors with overload protection
• Thermostatically controlled anti-condensation heater
• Manual override with end of travel mechanical stops
• Two auxiliary limit switches included with on-o ffunits
| Electric Actuator | Ball Valve | |||
|
Function
|
On/OfffforModulating
|
Cap
|
CF8M,CF8,WCB
|
|
|
Housing
|
Aluminum alloy,epoxy powder coated
|
Gasket
|
PTFE
|
R-PTFE
|
|
Gear
|
Steel/aluminum bronze
|
Ball Seat
|
PTFE | R-PTFE |
|
Screws
|
Stainles ssteel
|
Ball
|
SS316
|
SS304
|
|
Indicator Cover
|
Polycarbonate
|
Thrust Washer
|
PTFE | R-PTFE |
|
Shaft/Adaptor
|
Alloy steel
|
O-Ring
|
VITON
|
|
|
Seal
|
NBR
|
Stem Packing
|
PTFE | R-PTFE |
|
Lubrication
|
Aluminum based grease
|
Gland
|
SS304
|
|
|
Power Supply
|
24VDC,110VAC,220VAC
|
Spring Washer
|
SS304
|
|
|
Motor
|
Squirrel cage asynchronous motor
|
Stop Nut
|
SS304
|
|
|
Limit Switch
|
SPDT,250VAC 10A,each for Open and Close positions
|
Stop Washer
|
SS304
|
|
|
Rotation
|
90°(±10°) other rotation on request
|
Gland
|
SS304
|
|
|
Manual Operation
|
Mechanical handle standard
|
Handle
|
SS304
|
SS201
|
|
Conduit Entry
|
2xM18
|
Stem Nut
|
SS304 | SS201 |
|
Operating Temp
|
-20°C to+70°C
|
Body
|
CF8M,CF8,WCB | |
|
Ambient Humidity
|
Max.90%RH
|
Pin
|
SS201
|
|
|
Vibration Tested
|
XYZ10g,0.2~34Hz,30minutes
|
Anti-Static Device
|
SS316
|
SS304
|
|
Mounting
|
ISO5211
|
Stem
|
SS316 | SS304 |
|
Torque Output
|
30Nm to1000Nm (2000Nm on request)
|
Locking Device
|
SS316 | SS304 |
|
Self-locking device
|
Self-locking by worm and worm gear
|
Handle Cover
|
PLASTIC
|
|
| Model | Max Output Torque(N.M) |
Operating Time 90°(Sec.) 220VAC/24VDC |
Drive Shaft(mm) |
Motor(W)
220V/24VDC
|
Single-phsae
rated current(A)
220VAC/24VDC
|
Weight(kg)
|
|||
| Square | Deep | Round | Deep | ||||||
|
HEA003
|
30N.m
|
10/10
|
9X9 | 13.5 |
Ø12.6
|
26 | 8 |
0.3/2
|
2.1 |
| 11X11 | 15.5 | ||||||||
| HEA005 | 50N.m |
30/15
|
11X11
|
15.5
|
Ø12.6
|
26
|
10 |
0.24/2.4
|
3.6 |
|
14X14
|
18
|
||||||||
| HEA008 | 80N.m |
30/15
|
11X11 | 15.5 |
Ø15.78
|
26
|
10 |
0.25/2.5
|
3.6 |
| 14X14 | 18 | ||||||||
| HEA010 | 100N.m |
30/15
|
14X14
|
18
|
Ø15.78
|
28
|
15 |
0.35/3.5
|
4.6 |
|
17X17
|
22.5
|
Ø18.95
|
|||||||
| HEA015 | 150N.m |
30/15
|
14X14
|
18
|
Ø18.95
|
28
|
15 |
0.37/3.5
|
4.6 |
|
17X17
|
22.5
|
||||||||
| HEA020 | 200N.m |
30/15
|
22X22
|
26
|
Ø22.13
|
45 | 45 |
0.48/6
|
8.9 |
| HEA040 | 400N.m |
30/15
|
22X22
|
26 |
Ø28.48
|
45 | 60 |
0.5/6
|
8.9 |
| HEA060 | 600N.m |
30/15
|
27X27
|
32.5 |
Ø31.65
|
45 | 90 |
0.92/9
|
9.9 |
| HEA080 | 800N.m |
45/22
|
27X27
|
32.5 |
Ø31.65
|
45 | 180 |
1/12
|
14.3 |
| HEA100 | 1000N.m |
45/22
|
27X27
|
32.5 |
Ø31.65
|
45 | 180 |
1/12
|
14.5 |
| HEA200 | 2000N.m |
45/22
|
27X27
|
32.5 |
Ø31.65
|
45 | 200 |
1.5/15
|
14.5 |
