HEX Series Explosion-proof Electric Actuator
HEX Series Explosion-proof Electric Actuator
HEX Series Explosion-proof Electric Actuator
HEX Series Explosion-proof Electric Actuator
HEX Series Explosion-proof Electric Actuator
HEX Series Explosion-proof Electric Actuator

Hearken IP68 explosion proof electric actuators are widely used in potential environment of flammable and explosive, such as petroleum, chemical, power plant, liquid gas, winery and metallurgy etc. To ensure workers are away from danger, explosion proof is a must. For different industries, zones and divisions, different explosion proof grade is required.

Description

HEX series explosion proof electric actuators are used to control 0~90° rotation valve and other similar products, such as butterfly valve, ball valve, throttle, plug valves, louver valve, etc. It uses AC415V, 380v,240v.110 v ,DC12V,24 V and 220V voltage to be the driving source, and the actuator can be reset itself (with power down reset function ) ,4-20mA current signal or 0-10VDC voltage signal to be the controling signal, driving the valve to the required position,  so that realize the automation control. They can be widely apply to petroleum, chemical industry.electric power, metallurgy, pharmaceutical, papermaking, energy. water treatment, ship,textile, food processing, building automation and other fields.Meanwhile , which with small volume, light weight, elegant appearance, unique and compact structure, rapid in opening and closing , easy installation, small operation torque, easy operating, digital display for valve location, no need in maintenance and safe using and convenient, and many other advantages.





Performance  Features

●Small volume, light weight, easy installation and maintenance
●Simple and compact structure, 90 rotation, rapid in opening and closing
●Small torque in operating, light and handy
●Flow characteristics tending to straight line, good regulation performance.
●Multiple control signals, switch control.
●Proportional (modulation) control: 0-10vdc or 4-20mA.
●Feedback output can be selected 4-20mA, auxiliary switch and feedback potentiometer (0-1k)





Product Function

Long time diving working,the protection class can reach IP68.

The actuator is in charge state,with power down reset function,including open restting,closing resetting and no resstting,optional factory setting.



Model Parameter

HEX005

DC12V

DC24V

DC36V

DC110V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor Power (W)

20

20

20

20

20

20

20

20

20

Rated Current (A)

5

2.5

1.5

1.1

0.5

3

0.7

0.3

0.2

Standard Time / Torque

15S/30Nm

30S/50Nm

Optional Time / Torque

7.5S/15Nm    10S/20Nm    15S/30Nm

 15S/30Nm    20S/40Nm    30S/50Nm

Range of Turning Angle

Standard 0-90°, can be customized 0-360° any Angle

Optional Control Circuit

A Type/B Type/C Type/D Type/E Type/F Type/H Type/ZT Type/ZK Type

Weight (Kg)

3.1

Insulating Resistance

AC24V:100MΩ/250VDC    AC110V/AC220V/AC380C: 100MΩ/500VDC

Withstand Voltage Class

AC240V:500VAC 1minute, AC110V/AC220V:1500VAC 1minute, AC380V:1800VAC 1minute

Protection Class

IP67/IP68

Explosion-Proof

ExdII CT6

Installation

360°C at any angle

Electrical interface size

Outer wire 1-G1/2,, inner wire 1-G3/4, advised to use ᴓ9-ᴓ12 cable

Ambient Temperature

-20℃~+60℃

Optional Function

1.Diving type; 2.Clutch handwheel; 3.Heat the dehumidifier; 4.Over torque protection;

5.Power reset 6.High low temperature -40℃~+80℃

Model Parameter

HEX010

DC12V

DC24V

DC36V

DC110V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor Power (W)

20

20

20

20

20

20

20

20

20

Rated Current (A)

5

2.5

1.5

1.1

0.5

3

0.7

0.3

0.2

Standard Time / Torque

17S/40Nm

35S/100Nm

Optional Time / Torque

12S/30Nm    17S/40Nm    22S/100Nm

16S/40Nm    25S/60Nm    45S/100Nm

Range of Turning Angle

Standard 0-90°, can be customized 0-360° any Angle

Optional Control Circuit

A Type/B Type/C Type/D Type/E Type/F Type/H Type/ZT Type/ZK Type

Weight (Kg)

5.15

Insulating Resistance

AC24V:100MΩ/250VDC    AC110V/AC220V/AC380C: 100MΩ/500VDC

Withstand Voltage Class

AC240V:500VAC 1minute, AC110V/AC220V:1500VAC 1minute, AC380V:1800VAC 1minute

Protection Class

IP67/IP68

Explosion-Proof

ExdII CT6

Installation

360°C at any angle

Electrical interface size

Outer wire 1-G1/2,, inner wire 1-G3/4, advised to use ᴓ9-ᴓ12 cable

Ambient Temperature

-20℃~+60℃

Optional Function

1.Diving type; 2.Clutch handwheel; 3.Heat the dehumidifier;

4.Over torque protection; 5.Power reset 6.High low temperature -40℃~+80℃



Model Parameter

HEX020

DC12V

DC24V

DC36V

DC110V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor Power (W)

30

30

30

30

30

30

30

30

30

Rated Current (A)

6.6

3

1.6

0.68

0.3

4

0.7

0.35

0.2

Standard Time / Torque

15S/100Nm

30S/200Nm

Optional Time / Torque

3.5S/25Nm  10S/50Nm  15S/100Nm  30S/200Nm

15S/100Nm  20S/120Nm  45S/200Nm  60S/200Nm

Range of Turning Angle

Standard 0-90°, can be customized 0-360° any Angle

Optional Control Circuit

A Type/B Type/C Type/D Type/E Type/F Type/H Type/ZT Type/ZK Type

Weight (Kg)

6.7

Insulating Resistance

AC24V:100MΩ/250VDC    AC110V/AC220V/AC380C: 100MΩ/500VDC

Withstand Voltage Class

AC240V:500VAC 1minute, AC110V/AC220V:1500VAC 1minute, AC380V:1800VAC 1minute

Protection Class

IP67/IP68

Explosion-Proof

ExdII CT6

Installation

360°C at any angle

Electrical interface size

Outer wire 1-G1/2,, inner wire 1-G3/4, advised to use ᴓ9-ᴓ12 cable

Ambient Temperature

-20℃~+60℃

Optional Function

1.Diving type; 2.Clutch handwheel; 3.Heat the dehumidifier;

4.Over torque protection; 5.Power reset 6.High low temperature -40℃~+80℃



Model Parameter

HEX030

DC12V

DC24V

DC36V

DC110V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor Power (W)

40

40

40

40

40

40

40

40

40

Rated Current (A)

8

4

3

0.8

0.5

2

0.8

0.4

0.3

Standard Time / Torque

15S/150Nm

30S/300Nm

Optional Time / Torque

5S/50Nm  7.5S/60Nm  13S/100Nm

10S/80Nm  13S/100Nm  20S/150Nm  35S/300Nm

Range of Turning Angle

Standard 0-90°, can be customized 0-360° any Angle

Optional Control Circuit

A Type/B Type/C Type/D Type/E Type/F Type/H Type/ZT Type/ZK Type

Weight (Kg)

7.4

Insulating Resistance

AC24V:100MΩ/250VDC    AC110V/AC220V/AC380C: 100MΩ/500VDC

Withstand Voltage Class

AC240V:500VAC 1minute, AC110V/AC220V:1500VAC 1minute, AC380V:1800VAC 1minute

Protection Class

IP67/IP68

Explosion-Proof

ExdII CT6

Installation

360°C at any angle

Electrical interface size

Outer wire 1-G1/2,, inner wire 1-G3/4, advised to use ᴓ9-ᴓ12 cable

Ambient Temperature

-20℃~+60℃

Optional Function

1.Diving type; 2.Clutch handwheel; 3.Heat the dehumidifier;

4.Over torque protection; 5.Power reset 6.High low temperature -40℃~+80℃



Model Parameter

HEX040

DC12V

DC24V

DC36V

DC110V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor Power (W)

90

90

90

90

90

90

90

90

90

Rated Current (A)

15.2

8.6

4.5

2.8

1.2

8.1

2

0.9

0.4

Standard Time / Torque

15S/200Nm

30S/400Nm

Optional Time / Torque

7.5S/150Nm

7.5S/150Nm  15S/200Nm

Range of Turning Angle

Standard 0-90°, can be customized 0-360° any Angle

Optional Control Circuit

A Type/B Type/C Type/D Type/E Type/F Type/H Type/ZT Type/ZK Type

Weight (Kg)

12

Insulating Resistance

AC24V:100MΩ/250VDC    AC110V/AC220V/AC380C: 100MΩ/500VDC

Withstand Voltage Class

AC240V:500VAC 1minute, AC110V/AC220V:1500VAC 1minute, AC380V:1800VAC 1minute

Protection Class

IP67/IP68

Explosion-Proof

ExdII CT6

Installation

360°C at any angle

Electrical interface size

Outer wire 1-G1/2,, inner wire 1-G3/4, advised to use ᴓ9-ᴓ12 cable

Ambient Temperature

-20℃~+60℃

Optional Function

1.Diving type; 2.Clutch handwheel; 3.Heat the dehumidifier;

4.Over torque protection; 5.Power reset 6.High low temperature -40℃~+80℃











Model Parameter

HEX060

DC12V

DC24V

DC36V

DC110V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor Power (W)

120

120

120

120

120

120

120

120

120

Rated Current (A)

16

9

4.8

3

1.3

8.5

2.2

1

0.5

Standard Time / Torque

15S/300Nm

45S/600Nm

Optional Time / Torque

7.5S/150Nm  15S/300Nm  30S/400Nm

7.5S/150Nm  15S/300Nm  30S/400Nm

Range of Turning Angle

Standard 0-90°, can be customized 0-360° any Angle

Optional Control Circuit

A Type/B Type/C Type/D Type/E Type/F Type/H Type/ZT Type/ZK Type

Weight (Kg)

12.5

Insulating Resistance

AC24V:100MΩ/250VDC    AC110V/AC220V/AC380C: 100MΩ/500VDC

Withstand Voltage Class

AC240V:500VAC 1minute, AC110V/AC220V:1500VAC 1minute, AC380V:1800VAC 1minute

Protection Class

IP67/IP68

Explosion-Proof

ExdII CT6

Installation

360°C at any angle

Electrical interface size

Outer wire 1-G1/2,, inner wire 1-G3/4, advised to use ᴓ9-ᴓ12 cable

Ambient Temperature

-20℃~+60℃

Optional Function

1.Diving type; 2.Clutch handwheel; 3.Heat the dehumidifier;

4.Over torque protection; 5.Power reset 6.High low temperature -40℃~+80℃


Model Parameter

HEX100

DC12V

DC24V

DC36V

DC110V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor Power (W)

120

120

120

120

120

120

120

120

120

Rated Current (A)

19.2

11.6

7.6

3.4

1.4

9

2.4

1.1

0.45

Standard Time / Torque

25S/400Nm

50S/1000Nm

Optional Time / Torque

6S/150Nm  12S/300Nm  17S/300Nm  25S/400Nm  35S/500Nm

12S/200Nm  25S/400Nm  35S/600Nm

Range of Turning Angle

Standard 0-90°, can be customized 0-360° any Angle

Optional Control Circuit

A Type/B Type/C Type/D Type/E Type/F Type/H Type/ZT Type/ZK Type

Weight (Kg)

13

Insulating Resistance

AC24V:100MΩ/250VDC    AC110V/AC220V/AC380C: 100MΩ/500VDC

Withstand Voltage Class

AC240V:500VAC 1minute, AC110V/AC220V:1500VAC 1minute, AC380V:1800VAC 1minute

Protection Class

IP67/IP68

Explosion-Proof

ExdII CT6

Installation

360°C at any angle

Electrical interface size

Outer wire 1-G1/2,, inner wire 1-G3/4, advised to use ᴓ9-ᴓ12 cable

Ambient Temperature

-20℃~+60℃

Optional Function

1.Diving type; 2.Clutch handwheel; 3.Heat the dehumidifier;

4.Over torque protection; 5.Power reset 6.High low temperature -40℃~+80℃



Model Parameter

HEX200

DC12V

DC24V

DC36V

DC110V

DC220V

AC24V

AC110V

AC220V

AC380V

Motor Power (W)

180

180

180

180

180

180

180

180

180

Rated Current (A)

20

12

8

3.6

1.5

9.5

2.6

1.4

0.6

Standard Time / Torque

30S/500Nm

75S/2000Nm

Optional Time / Torque

6S/150Nm  12S/300Nm  17S/300Nm  25S/400Nm 30S/500Nm

12S/200Nm  25S/400Nm  35S/600Nm  50S/800Nm

Range of Turning Angle

Standard 0-90°, can be customized 0-360° any Angle

Optional Control Circuit

A Type/B Type/C Type/D Type/E Type/F Type/H Type/ZT Type/ZK Type

Weight (Kg)

13.5

Insulating Resistance

AC24V:100MΩ/250VDC    AC110V/AC220V/AC380C: 100MΩ/500VDC

Withstand Voltage Class

AC240V:500VAC 1minute, AC110V/AC220V:1500VAC 1minute, AC380V:1800VAC 1minute

Protection Class

IP67/IP68

Explosion-Proof

ExdII CT6

Installation

360°C at any angle

Electrical interface size

Outer wire 1-G1/2,, inner wire 1-G3/4, advised to use ᴓ9-ᴓ12 cable

Ambient Temperature

-20℃~+60℃

Optional Function

1.Diving type; 2.Clutch handwheel; 3.Heat the dehumidifier;

4.Over torque protection; 5.Power reset 6.High low temperature -40℃~+80℃
HEX005 Basic Actuator Outline Dimension (Unit:mm)

Technical Parameter and Specifications (On/Off or Modulating Version)

Straight Mounted Parameter

Star Adaptor

□9x9  □11x11  □14x14

Flange Centre Distance

F03     F05

Valve Stem

Height≤22mm

Technical Parameter and Specifications (On/Off or Modulating Version)HEX010 Basic Actuator Outline Dimension (Unit:mm)



Straight Mounted Parameter

Star Adaptor

□9x9  □11x11  □14x14

Flange Centre Distance

F03     F05    F07

Valve Stem

Height≤22mm


Technical Parameter and Specifications (On/Off or Modulating Version)HEX020 Basic Actuator Outline Dimension (Unit:mm)

Straight Mounted Parameter

Star Adaptor

□9x9  □11x11  □14x14

□17x17

Flange Centre Distance

F03     F05    F07

Valve Stem

Height≤22mm


Technical Parameter and Specifications (On/Off or Modulating Version)HEX030 Basic Actuator Outline Dimension (Unit:mm)

Straight Mounted Parameter

Star Adaptor

□9x9  □11x11  □14x14

□17x17   □22x22

Flange Centre Distance

F03     F05    F07

Valve Stem

Height≤22mm

HEX040 Basic Actuator Outline Dimension (Unit:mm)

Technical Parameter and Specifications (On/Off or Modulating Version)

Straight Mounted Parameter

Star Adaptor

□17x17  □22x22  □27x27

Flange Centre Distance

F07     F10

Valve Stem

Height≤22mm



HEX060 Basic Actuator Outline Dimension (Unit:mm)

Technical Parameter and Specifications (On/Off or Modulating Version)

Straight Mounted Parameter

Star Adaptor

□17x17  □22x22  □27x27

Flange Centre Distance

F07     F10

Valve Stem

Height≤22mm

HEX100 Basic Actuator Outline Dimension (Unit:mm)

Technical Parameter and Specifications (On/Off or Modulating Version)

Straight Mounted Parameter

Star Adaptor

□17x17  □22x22  □27x27

Flange Centre Distance

F07     F10

Valve Stem

Height≤22mm




HEX200 Basic Actuator Outline Dimension (Unit:mm)

Technical Parameter and Specifications (On/Off or Modulating Version)



Straight Mounted Parameter

Star Adaptor

□17x17  □22x22  □27x27

Flange Centre Distance

F07     F10

Valve Stem

Height≤22mm


Related Products

hea(m)multiple turn electric actuator

HEA(M) Multi Turn Electric Actuator

HML Series Linear Electric Actuator

HML Intelligent Linear Electric Actuator

HQT Series Explosion proof Electric Actuator

HQT Manual Override Explosion proof Electric Actuator

HEA-P Spring Return Electric Actuator

News

2024

/

18
Dec

Comprehensive Guide to Electric Butterfly Valves: Principles, Applications, and Advantages

Electric butterfly valves play a crucial role in industrial automation, off...

2024

/

11
Dec

Difference Between T-Type and L-Type 3-Way Ball Valves

When it comes to controlling the flow of fluids or gases in industrial syst...

2024

/

04
Dec

What is a Sanitary Ball Valve?

Learn the differences between sanitary ball valves and diaphragm valves, th...

2024

/

27
Nov

What is the Difference Between Single-Acting and Double-Acting Positioners?

Learn the key differences between single-acting and double-acting positione...

GET A QUOTE

Get in Touch

×
We value your privacy
We use cookies to provide you with a better online experience, analyse and measure website usage, and assist in our marketing efforts.
Accept All
